• Electric ratings: up to 63A, 230V,  AC50/60Hz;
• No. of mounted units: 3, 5;
• On-load current A: 63;
• Protection degree: IP65;
• Standard: IEC61439-3(EN60670-24)

Features

• Special designed with excellent enclosure capability; with high protection degree up to IP65, applicable for outdoor mounting.
• The interiorly mounted MCBs are all in compliance with relative IEC standards, 9mm modularized electric components are applicable, as well;
• On request, various circuit combinations can be assembled; and the mounting capacity of the product units can be taken to 3~ 5units;
• Convenient and reliable operation, having exposed handle, and all live parts to be mounted inside the wall box;
• The consumer unit is designed with internal terminal blocks for connection of neutral line and protective grounding
